Product Description

High-Resolution Display: 7-inch touchscreen LCD with 800×480 resolution, displaying ECG waveform, heart rate, time, and operational conditions
◎ Comprehensive ECG Analysis: Supports 12-lead simultaneous acquisition, with automatic, manual, and rhythm analysis modes, including R-R histogram and trend chart

◎ Advanced Filtering: Includes EMG, drift, and AC filters for noise reduction and signal clarity
◎ Compact and Lightweight: Designed for portability, with a small form factor and lightweight build (2.25 kg)
◎ Defibrillation Protection: Protects circuits during defibrillation and pacemaker usage
◎ Thermal Printing System: Integrated thermal printer supporting multiple channel outputs and variable printing speeds
◎ Built-in Storage: Can store up to 200 reports with options for external SD card storage
◎ Rechargeable Battery: Features a Li-poly rechargeable battery for extended portability and reliability during use.

Product Features

• Lead System: Supports 12-lead acquisition (Standard or Cabrera) with simultaneous 12-lead display.

• Input Circuit: Floating circuit design with defibrillation protection for enhanced safety.
• LCD Display: 800×480 7-inch touchscreen showing ECG waveforms, operation conditions, heart rate, and more.
• Safety Compliance: IEC class II, type CF certified.
• Sampling Rate: 1000 samples per second per channel for high-resolution signals.
• Input Dynamics: ±500 mV, ensuring wide signal capture.
• Operation Modes: Automatic, manual, and single-channel modes, with 60-second compressed records and rhythm analysis (R-R histogram and trend chart).
• Advanced Filtering: Includes AC filter (50/60 Hz, -20 dB), EMG filters, and drift filters for superior noise reduction.
• CMRR: >100 dB (with AC filter) for exceptional signal clarity.
• Printing System: Integrated thermal printer with speed options (8 dots/mm for vertical, 40 dots/mm for horizontal) and multiple output configurations.
• Printing Output: Options for 3-channel, 3+1 channel, 6-channel, and 6+1 channel formats.
• Paper Size: 110 mm×20 m roll or Z-fold thermal paper.
• Built-in Storage: Stores up to 200 reports, with support for external SD card storage.
• Power Supply: 12.5V 1800mA Li-poly rechargeable battery with AC power compatibility (220V/50 Hz).
• Lightweight Design: Machine weight of 2.25 kg (excluding accessories) for easy portability.
• Protection Features: Safeguards against defibrillation and pacemaker interference.
• Indicators: Lead-off detection system for enhanced usability.
• Machine Dimensions: Compact size at 285 mm × 200 mm × 55 mm.
